Головной кардиоидный конденсаторный микрофон для радиосистем с разъемом TA4F, оранжевый
- Type: Electret Condenser
- Frequency Response: 45 to 20,000 Hz
- Polar Pattern: Unidirectional (Cardioid)
- Output Impedance @ 1 kHz: 600 Ω
- Audio Output Level: -50 dBV/Pa
- Signal-To-Noise Ratio[1] @ 1 kHz: 66 dB
- Maximum SPL[1] 1000 Ω load, @ 3% THD: 145.0 dB
- Dynamic Range[1]: @ 1 kHz, 1000 Ω load: 117.0 dB
- Equivalent Output Noise[1] Typical, A-Weighted: 28 dB
- Power Requirements: +5 V DC (nominal), 10 V maximum (DC bias)
- Polarity: Positive pressure on diaphragm produces positive voltage on pin 3 with respect to pin 1
- Cable: 1.1 m (45 in.)
- Connector: TA4F
- Net Weight: 60 g (2.11 oz.)
