Технические характеристики
- Type: Single-mechanism Compact Disc Player
- Audio Channels: 2 Channel Stereo
- Quantization: 16-bit linear
- Sampling Frequency: 44.1kHz at Normal Pitch
- Frequency Response: 5 to 20,000Hz
- Total Harmonic Distortion: 0.004% (at "CD Pitch=0Fix" mode of the preset function
- Signal to Noise Ratio: 104 dB (at "CD Pitch=0Fix" mode of the preset function
- Dynamic Range: 100 dB (at "CD Pitch=0Fix" mode of the preset function
- Channel Separation: 90 dB (at "CD Pitch=0Fix" mode of the preset function
- Oversampling: 8-times
- Line Output (Unbalanced): RCA Jack
- Output Level: 2.0 V at 0 dB recorded Disc at 1 kHz
- Load Impedance: 10 kOhms or more
- Line Output (Balanced): 3-pin XLR (active balanced) (Pin 2 hot)
- Output Level: +18 dBu at 0 dB Disc
- Output Adjust Range: +22 dBu to -20 dBu
- Load Impedance: 600 ohms
- Digital Output (RCA Jack): SPDIF or IEC-958 Type II
- Headphone Output: Stereo
- Output Level: 7 mW
- Load Impedance: 33 ohms
- Variable Speed Control: +/-12% max.
- Frame Search Accuracy: 1/75 second (CD-DA)
- Remote: 9P D-Sub (Serial port)
- IR Remote Control Sensor
- 25P D-Sub (Parallel)
- Optional: RC-680 Remote Control
- Power Source: 120V AX +/-10%, 60Hz
- Power Consumption: 15 Watts
- Installation: 19-inch rack mountable (2U)
- Dimensions (excluding height of keys, connectors): 482(W) x 88(H) x 252(D) mm
- Weight: 4.7 kg
